Light source:
25X10W 4000K Quad color LED
Voltage:
AC100-240V  50/60Hz
Power:
300W
Material:
metal
Service:
OEM,ODM
Shippment:
International express/ Air/ Sea
Payment:
TT/ Paypal/ Western Union
CE:
Great
Inquiry
Product Details
Mars Lighting pays great attention to details of stage lighting equipment.Closely following the market trend, Mars Lighting uses advanced production equipment and manufacturing technology to produce stage lighting equipment. The product receives favors from the majority of customers for the high quality and favorable price.
  • disco matrix led with RGBW tri-color COB LED fro night bar Marslite 11
Company Advantages
1. Marslite big led matrix is manufactured as per the international quality norms and well-defined industry parameters.
2. The product features both soft cushioning for foot protection and firmer cushioning for propulsion. The materials used in the forefoot and rearfoot part vary for different protection functions.
3. The product is hypo-allergenic. It contains few allergy-producing substances such as nickel, but not enough to cause irritation.
4. big led matrix innovated by Guangzhou Mars Lighting Technology Co., Ltd. is highly marketable in world markets.
5. With more emphasis on big led matrix , we strive to provide high-quality matrix led , technologies and services.

Product Video

bg

Product Overviews

bg

MS-MQD25  25X10W 4000K Quad color LED

  • The 5X5 head LED matrix bar lgiht with RGBW tri-color COB LED, could be assembly in different shape and show

  • different amazing wash effect.

  • Get ready to create the a rich display of RGBW mixed color at your next event.

  • Creates smooth and rich RGBW color mixing and can be used as a Wash/Bar or Pixel Mapped for stunning visual effects.

  • Built-in sound active, ArtNet, DMX and master/slave, foot controller mode.

  • Great for stage lighting, bands, or night clubs.


Technical Data

bg





LIGHT SOURCE:

LEDs: 25X10W 4000K Quad color LED

LEDs average lifespan: >50,000hrs

Drive mode: constant current

Drive current(mA): 667




POWER SUPPLY:

Power consumption: Max. 300W

Auto switching power supply unit

Power supply: AC100V-240V,50/60Hzz(auto-ranging)

Power In/Out: Powercon, daisy chain




OPTICS:

Beam angle: 48°

Lens: Fronst lens or Clear lens optional

Flicker free(refresh rate>4K Hz)

Light output(full bright): 11270LUX@1m, 4110LUX@2m, 798LUX@5m




CONTROL AND PROGRAMMING:

Control mode: DMX,ArtNet,Master/Slave and Sound-active

DMX channels: 1/4/5/25/75/100CH

Setting and addressing:4-digit LED

DMX data In/Out: XLR 3Pin





EFFECTS:

8 bit smooth dimming

Electronic dimmer:0-100% linear

Electronic strobe:1-20 flashes/sec

Built-in color changing macro, fade in & out macro

Built-in auto programs and speed adjustable

BODY:

Housing: Metals, black baking finished

COOLING :

Cooling: forced air convection, with four silent fan







ENVIRONMENT AND PHYSICAL:

IP rating: IP20

Certificate: CE and RoHs

Environment temp: -20℃-40℃

Light Size:58*58*12cm

N.W.:13kg
