different blind matrix beam series for KTV
1. The development of Marslite rigid light bar has taken various subjects into consideration. They are mainly foot biomechanics and the principle of structural mechanics and ergonomics ( mainly referring to physiological structure development). It has mature product structure and production process
2. Being the prime blind matrix company, we dedicated ourselves into developing and designing the best led matrix rgb for customers. Our products emphasizes the value of innovation and design
3. Under the advantage of rigid light bar , blind matrix can bring customers great usage experience. Our lights can meet the requirements of ROHS
4. It is conducted by professional inspection team at every step from design to finish. OEM and ODM orders will be welcome as well
Product Overviews
MS-CB50 5pcs 10W COB RGB 3in1 LEDs
◪The Five head LED matrix bar lgiht with RGB tri-color COB LED, could be assembly in different shape and show
◪different amazing wash effect.
◪Get ready to create the a rich display of RGB mixed color at your next event.
◪Creates smooth and rich RGB color mixing and can be used as a Wash/Bar or Pixel Mapped for stunning visual effects.
◪Built-in sound active, Auto, DMX and master/slave, Matrix software mode.
◪Great for stage lighting, bands, or night clubs.
Technical Data
LIGHT SOURCE: | LEDs: 5pcs 10W COB RGB 3in1 LEDs |
LEDs average lifespan: >50,000hrs | |
Drive mode: constant current | |
Drive current(mA): 667 | |
POWER SUPPLY: | Power consumption: Max.50W |
Power supply: AC100V-240V,50/60Hzz(auto-ranging) | |
OPTICS: | Flicker free(refresh rate>4K Hz) |
Light output(full bright): 630LUX@1m, 159LUX@2m, 26LUX@5m | |
CONTROL AND PROGRAMMING: | Control mode: DMX,auto run,Master/Slave, Matrix software and Sound-active |
DMX channels: 1, 3, 5,7,15, 18CH | |
DMX data In/Out: XLR 3Pin(XLR 5pin is optional) | |
EFFECTS: | 8 bit smooth dimming |
Electronic dimmer:0-100% linear | |
Electronic strobe:1-20 flashes/sec | |
Built-in color changing macro, fade in & out macro | |
Built-in auto programs and speed adjustable | |
BODY: | Housing: die-cast aluminium, black baking finished |
COOLING : | Cooling: forced air convection, with one silent fan |
ENVIRONMENT AND PHYSICAL: | IP rating: IP20 |
Certificate: CE and RoHs | |
Environment temp: -20℃-40℃ | |
Light Size:62*15*16cm | |
N.W.: 3.5kg | |
G.W.:4.5kg | |
Package Size:68*18*21CM |
Technical Details
Effect diagram
Effect picture - colorful
Different visual effects
Effect picture - colorful
Different visual effects
Effect picture - colorful
Different visual effects
Effect picture - colorful
Different visual effects
Test chart
Production line
Packing
Our Services
◪ Impeccable after-sales sevice will solve all worries after you buy our products.
◪all your inquires about us or our products, we will reply you in detail within 24 hours.
1. OEM/ODM is available
---Printing logo on customized products
---Customized design and material
---Customized packing for your products
---Provide your ideas, we have specialized engineers to help you design
2. every process will be checked by responsible QC which insure the products' quality.
3. Samples could be prepared for you on time
4. Guide you how to install
5. Compensate for the product if some quality problems on our side
6. If you come to our factory, pls inform us in advance,we pick you up if our driver available.
Our advantage
Experience:We are professional led stage lighting factory for ten years, It is also one of the largest stage lighting manufacturer and develop in China.Our products are exported to more than 70 countries including Western Europe, Central America, South America and southeast Asia through international sales channels.
Custom service：Our products can be OEM, to meet your special requirements.
---Printing logo on customized products
---Customized design and material
---Customized packing for your products
---Provide your ideas, we have specialized engineers to help you design
Company strength
---We have rich experience R&D engineer and we have strong ability for OEM projects.
---We have wee-trained and professional sales&after- sale services
---ISO9001 certification enterprise.Chinese famous brand for many years.
---We are has been inspected onsite by TÜV Rheinland , a third-party verification agency on alibaba. They offer Assessment Reports and Verified Videos. That gives buyers trust and authoritative information about suppliers.
Company Features
1. Guangzhou Mars Lighting Technology Co., Ltd. is one of the China manufacturers specializing in the design, manufacture, and distribution of rigid light bar . We are widely accepted by overseas customers. We have our own design team and the engineering development team. They have strong design and development capabilities and a profound understanding of the product and market trends. This makes them continuously introduced new distinctive products.
2. Our products have been widely used by domestic and foreign customers. We have won praise from these customers for the quality we provide. Currently, we have a presence in foreign markets.
3. Our greatest assets are the very capable personnel, many of whom are recognized and accepted as leading experts in their field. They bring literally decades of combined knowledge and expertise to our production. Placing emphasis on blind matrix is essential for the future development of Marslite. Please contact.
